Enclosed Conductor Rail

LEITAI HFP56 Series Enclosed Type Conductor Rail

Feature:

1.Capacity from 50 – 240 A.
2.Euro Design and popular in Euro, South America, Middle East Area.
3.Easy for maintenance

Advantage:

1.PVC Housing: Good material, compact design good performance and long-service life.
2.Spare parts: Fire-proofing material, Good galvanized quality, compact design, easy for installation.
3.Collector: Nylon material , high quality carbon bush, half meter cable for easy connection.
4.Others: Line feed is available, bolted connection is available.


Model Pole No. Max. current
(A) 		Max. voltage
(V) 		Resistance
(Ω) 		Weight
(kg)
HFP56-4-8/35 4 35 660 1.944 2.09
HFP56-4-10/50 4 50 660 1.656 2.16
HFP56-4-12/65 4 65 660 1.321 2.23
HFP56-4-15/80 4 80 660 1.137 2.3
HFP56-4-20/100 4 100 660 1.011 2.43
HFP56-4-25/120 4 120 660 0.713 2.56
HFP56-4-35/140 4 140 660 0.522 2.95
HFP56-4-50/170 4 170 660 0.337 3.25
HFP56-4-70/210 4 210 660 0.265 3.85
HFP56-4-80/240 4 240 660 0.223 4.16
